I have an Apple Wireless Mighty Mouse, I have to say that it is quite nice, despite what everybody says about it, overall it is a nice product. A bit pricey I know, but being able to use it without taking any USB port certainly deserves it (at least for me).
The only problem I have with it its that the scroll ball gets stuck really easy, especially for me that I sweat a lot I ended up learning to not use the ball, and that’s plain silly. Heck, I paid for the scroll wheel.
Now, you can look around the net for “clean mighty mouse” or “mighty mouse not scrolling” and you’ll find lots of tips and tricks, here is a rundown:
-Official Apple way: turn it over and wun it up and down a few times on a cloth, carefully.
-Use a qtip and some alcohol/WD-40/whatever and clean it
-Rub it on your pants
I tried all of those, and most of them allowed me to keep it using for about a month before it got stuck again, I was starting to get pissed off (and considering buying a new mouse), so I decided to crack it open.
Note that the above methods DO work, however there are a few catches: first of all, you have to do them as soon as you have some problems, the longer you keep the ball stuck the more difficult it will be to clean; second, always make it SLOWLY and CAREFULLY, I failed to do both and ended up with an screwed up mouse (more on that later…) and third: while these methods free the ball, they fail to clean it properly.
So my recommendation is: try the above mentioned, if it fails, go to Apple. Now, if this advice is not good for you, then keep reading.
My mouse had 2 big problems: it didn’t vertically scroll and the middle button didn’t work (this is why you should rub carefully!). Time to get some tools and open it.
I have to remind everybody that cracking open your mouse invalidates your warranty, and that you have to BREAK it in order to open it, so if you don’t want your cute white friend to look bad you should NOT do this.
To open it, just google, there are lots of tutorials, basically you have to take a knife (I used a paper knife, we call them “cutters”) and ran it around the sides from the hole at the squeeze buttons. This is hard, real hard, so be careful, you may break the outer ring.
Once you have removed the ring, inside there are 2 plastic pins, use a screwdriver to take them out, then there are the pivots (where the body rotates for the click) just take one out and the other is easy. Before you remove the top part you have to unplug two flat cables, be careful!. To remove a flat cable just look at the jack, you’ll see it has a small black piece the slides in, all you have to do is slide it out and the cable will be free. Don’t pull the cable before it is completely free, otherwise you can damage the board or the cable.
Once that is done, put the body aside and keep the top part, you’ll see the scroll ball mechanism, take it out (it has 3 screws) and then you can use a small flat head screwdriver to take it apart.
Now take a look at it, you’ll see lots and lots of dirt in there, using a screwdriver and a small brush remove all of it. Inside the mechanism there is the ball (clean it with water, careful that you don’t drop it into the drain!) and 4 small magnetized rolls. Clean each of these rolls carefully (I used a brush, maybe yo could use WD-40 or something, but I am not sure if it can damage something).
Once you have cleaned everything, you’ll see that there is a small membrane (gray maybe) that is below the metal spring, this membrane is used to press the circuit below to detect a middle click. Mine had a big hole in it :S. While cleaning the mouse I probably damaged it (another reason to be careful).
Looking around the net I found a solution: aluminum foil. These kind of buttons work by having a membrane coated with a conductive ink, once you press it, the coat bridges a circuit below. In my case this coating was gone, so I put a small piece of foil over the circuit, below the broken membrane and it worked.
I don’t know if it’ll work for long, but its better than nothing.
Once you have cleaned and repaired your mouse, its time to put it together. The easiest way is to first connect the green cable (the one from the face buttons) and then the scroll’s cable. You have to insert the cable all the way in the connector, then push the slider inside, its a bit tricky, but not difficult.
Once you have it assembled you’ll have to glue the ring, before you do it use your mouse for a while and see if it is fixed, once you are confident enough put a few drops of glue and let it dry.
I “glued” mine using some tape, because I wanted to try the foil fix a bit longer, but its up to you.
So, that’s it, a (not so) simple way to fix your mouse, I would love to post pics but I am still having trouble with the server (and I haven’t bothered to find out why) and besides, there are plenty of pics/videos around the net.
That’s it for today, hope it helps somebody.
Take care
Update: Looks like the foil fix is not too good, so here’s the improved one: take a small foil pice (about 1×1 mm) and then glue it to the bottom of the membrane (if there is still some left, mine had), let it dry a couple of minutes and try it.
